H3C S3600 Series Installation Manual

Installation Manual
H3C S3600 Series Ethernet Switches Chapter 1 Product Overview
1-29
Table 1-12 LEDs on the front panel of the S3600-28P-PWR-SI/S3600-28P-PWR-EI
LED Mark Color Indicates
Solid green
The system passes a POST
and is operating normally.
Flashing green (1 Hz)
The system is running a POST
or is downloading software.
Solid red
The POST of the system fails or
a serious fault is detected.
Flashing yellow (1 Hz)
Some ports fail to pass the
POST and some functions are
disabled.
AC
Power
LED
PWR
OFF The power is disconnected.
Solid green
Both the internal AC power
supply and the DC input are
normal.
Solid yellow
The internal AC power supply
fails or is disconnected, but the
DC input is normal.
DC LED RPS
OFF The DC input is not connected.
Speed Solid green
Rate information of the
10Base-T/100Base-TX
Ethernet ports and the
1000Base-X SFP ports.
Duplex Solid yellow
Duplex information of
10Base-T/100Base-TX
Ethernet ports and the
1000Base-X SFP ports.
Mode
LED
Mode
PoE
Flashing green
(1 Hz)
PoE information on 10/100M
port.
