299
PARAMETERS
June 1999
96-8000
D:Y SW ON FLY This bit enables switching on the fly, as the spindle motor is
accelerating or decelerating through the switch point. If bit 18 is not
set, this switch will be ignored.
5 AX TOFS -X This bit is used with the G143 (modal 5 axes tool length
compensation) on machines with a Gimbaled Spindle. If it is set to 1,
this means that when the corresponding rotary axes is moved, the
sign of the X Position must be inverted. Normally, this bit should be
set to 0.
5 AX TOFS -Y This bit is used with the G143 (modal 5 axes tool length
compensation) on machines with a Gimbaled Spindle. If it is set to 1,
this means that when the corresponding rotary axes is moved, the
sign of the Y Position must be inverted. Normally, this bit should be
set to 0.
5 AX A MOV B This bit is used with the G143 (modal 5 axes tool length
compensation) on machines with a Gimbaled Spindle. The B axes
normally moves the A axes, but if this is not true, this bit can be set
to change which is the inner axes. Normally, this bit should be set to
0.
S MNT BIT 1 Bits 26, 27, and 28 work together to specify the type of sidemount
tool changer that is installed on a vertical mill. The following table
shows the bit combinations that must be used:
Bit 28 27 26
0 0 0 No side-mount tool changer installed
0 0 1 Serpentine 1
0 1 0 Serpentine 2
0 1 1 Serpentine 3
1 0 0 Disk 1
1 0 1 Disk 2
1 1 0 Disk 3
1 1 1 Disk 4
S MNT BIT 2 Bits 26, 27, and 28 work together to specify the type of sidemount
tool changer that is installed on a vertical mill.
S MNT BIT 3 Bits 26, 27, and 28 work together to specify the type of sidemount
tool changer that is installed on a vertical mill. ]
TL DR SWITCH This bit specifies the too carousel door configuration. If it is set to 0,
this indicates the configuration where the door id driven open by a
timed operation. If it is set to 1, this indicates the door is spring
loaded closed and is driven open by a timmed operation against the
door open switch.
HS2 SDMTCRSL This parameter bit is for the HS-2 sidemount tool changer. It must be
set to 1 on all HS-2 mills, and 0 on all other mills.
