Hach BioTector B7000 User Manual

Page 38
Table 2 BioTector analysis enclosure major components
1
Fan
2
Cooler
3
Ozone Generator
4
Exhaust Valve, MV1
5
Injection Valve, MV7
6
Purge Valve, MV51
7
Non-return Valve (Check Valve)
8
Mass Flow Controller
9
Ozone Destructor
10
Oxygen Regulator
11
Sample Valve (ARS Valve), MV4
12
Dual Cell Photometer Module (DCP Module)
13
NDIR CO
2
Analyzer
14
Oxidized Sample Catch-pot/Cleaning Vessel
15
Acid Valve, MV6
16
NP Sample Valve, LV3
17
DI Water Valve, LV2
18
TN Cleaning Valve, LV1
19
Circulation Pump (KNF 300), P2
20
Multi-Component Reactor (MCR)
21
PFA Glass Beads Chamber
22
Sample Pump, P1
23
Acid Pump, P3
24
Base Pump, P4
25
N Pump (Nitrogen Pump), LP1
26
Vent
27
Sample Out Valve, MV5
28
Cleaning Valve, MV3
29
Zero Water Valve (Zero Calibration Valve), MV15
30
Manual/Calibration Valve (Span Calibration Valve), MV9
