Remote indicator mounting
N O T I C E
In accordance with UL 61010-1, the remote indicator must be installed 1.5 m (4.9 ft) or more from patients in the
hemodialysis treatment room.
Attach the remote indicator to a wall or ceiling in the treatment room. The fasteners are supplied by
the user.
Note: An illustration is supplied for each step number starting at step 3.
1. Identify the installation location for the remote indicator.
2. Put the cable for the remote indicator through the wall or ceiling from the analyzer to the
installation location of the remote indicator.
The cable is supplied by the user. Refer to Specifications on page 3 for the cable specifications.
English
27
