Product components
Make sure that all components have been received. Refer to Figure 4. If any items are missing or
damaged, contact the manufacturer or a sales representative immediately. Keep the packaging for
later use.
Figure 4 Product components
1 CM130 analyzer 5 Thumbscrew
2 Installation kit (refer to Figure 5) 6 Colorimeter
3 Remote indicator 7 Performance check kit (refer to Figure 7)
4 Blade terminal 8 Monthly maintenance kit
9
(refer to Figure 6)
9
The monthly maintenance kit is not supplied with the instrument.
12 English
