Specifications
Specifications are subject to change without notice.
Table 1 General specifications
Specification Details
Dimensions
(W x H x D)
Analyzer: 37.0 x 53.8 x 22.6 cm (14.6 x 21.2 x 8.9 in.)
Remote indicator: 12.3 x 29.4 x 10.7 cm (4.8 x 11.6 x 4.2 in.)
Enclosure Enclosure rating: IP52 rated with the door closed
Enclosure material: PC/ABS case, PC door, PC hinges and latches, 316 SST
hardware
Remote indicator material: PC/ABS
Display 10.9 cm (4.3 in.) color display, back-lit LCD, WQVGA
Weight Analyzer: 8.9 kg (19.6 lbs)
Remote indicator: 1.1 kg (2.5 lbs)
Mounting Analyzer: Wall
Remote indicator: Wall or ceiling
Protection class I
Pollution degree 2
Installation category II
Power requirements Analyzer: 100 to 240 VAC, 50/60 Hz; 1 A maximum
Remote indicator: Power is supplied by the analyzer.
Power-loss alarm: Power is supplied by a lithium coin battery CR2032 (3 V) that is in
the remote indicator.
Recommended operating
temperature
15 to 30 °C (60 to 85 °F)
Safe operating
temperature
5 to 40 °C (41 to 104 °F)
Operating humidity 5 to 90% non-condensing at 30 °C (85 °F) maximum
Storage temperature -20 to 60 °C (-4 to 140 °F)
Fittings Sample line: ¼-in. OD push-to-connect fitting for plastic tubing
Drain line: slip-on fitting for ½-in. ID soft plastic tubing
Cabling
1
Ethernet: 100 m (328 ft) maximum, Ethernet cable with an RJ45 connector
Remote indicator: 762 m (2500 ft) maximum, CAT5e/CAT6 type Ethernet cable with
four twisted pairs of 24 AWG solid copper wiring.
Make sure that the cable shielding includes an inner foil wrap around all of the pairs
and an outer braid, also known as SFTP or SF/UTP. Do not use stranded or copper-
clad aluminum conductors.
Sample Pressure: 276 to 689 kPa (40 to 100 psi) nominal
Pressure spikes: 827 kPa (120 psi) or less
Flow rate: 250 mL/minute minimum
Temperature: 15 to 30 °C (60 to 85 °F)
Filtration: 15 µm or less
Refer to Table 15 on page 72 interfering substances.
1
Cabling is supplied by the user.
English 3
