AB182, 242, 282, 302, 382, 482MCERA
2m2m 1m1m4m 3m 3m 4m0m
1.5m/s
1.5m/s
1.0m/s
1.0m/s
0.5m/s
2.7m
2m
1m
0m
0.5m/s
a. Cooling / Air velocity distribution
Cooling
Blowy angle: 40
Air velocity distribution
b. Cooling / Temperature distribution
Cooling
Blowy angle: 40
Temperature distribution
2.7m
27℃
25℃
22℃
27℃
25℃
22℃
4m 3m 2m2m 1m1m 3m 4m0m
2m
1m
0m
