Choice of Blowing Wind from Blower
(a) Keep a gradient (1/50-1/100) of the drainpipes and avoid lobbing or curving.
(when using the high performance lter)
• Proper Piping • Improper Piping
Static Pressure Range
unit: Pa
4. Drainpipes
The blower is provided with a red terminal, a white terminal and a blue terminal. The standard wind choice has
been set before delivery. When the use of optional components, such as the high performance lter, causes the
static pressure rising, change the connection of the connector mounted on the side of the control cabinet, as shown
as follows.
(b) When connecting the drainpipe to the equipment, don’t apply too much force on one side of the equipment.
Meanwhile, the piping should be positioned as close to the equipment as possible.
(c) For the drainpipe, the general purpose hard PVC tube can be purchased at local shops. During the connection,
insert the end of PVC tube into the wash port and fasten it with drainage hose and thread clip. Binding agents
shouldn’t be used to connect the wash port and drainage hose.
Standard Static
Pressure
Max. Static
Pressure
50 100
Air outlet port
Avoid curving
Don't put pipe
into water
Gas pipe
Liquid pipe
Drain pipe
365mm
1.5m ~2 m
Gradient of 1/100 or over
Hanging bolt
Standard blowing wind(at delivery) High-speed blowing wind Low-speed blowing wind
Orange
Blue
Yellow
Black
Black
Red
Yellow
Blue
Yellow
Black
Yellow
Blue
Blue
Red
Red
Black
Orange
Yellow
Orange
Black
Red
Yellow
Blue
Avoid lobbing
Motor
Motor
Motor
Black
Heat insulator
