Constant Air Volume Duct
Type Indoor Unit (AD*MQERA)
MODEL AD072MQERA AD092MQERA
Cabinet
Cabinet Coating Type Plastic Plastic
Cabinet Salt Spray Test
Duration
Hour 48 48
Control Box IP Class I I
Construction
Sheet Metal Thickness 1.2 1.2
Drain Pan Material EPS EPS
Drain Pan Insulation HF-1 HF-1
Drain Pump Option mm 600 600
Branch Outlet Option NO NO
Indoor Wall
Material Hot zinc plate Hot zinc plate
Thickness mm 1.2 1.2
Double or Single Skin Single Single
Air Filter
Material PP PP
Mesh 100 100
Pressure Drop Pa 5 5
Piping
dimension
Liquid pipe mm 6.35 6.35
Gas pipe mm 9.52 9.52
Drain hose mm 31.5 31.5
Fresh air dimension mm Ø170 Ø170
Sound pressure level (H/M/L) dB(A) 30/25/23 30/25/23
Sound power level (H/M/L) dB(A) 34/29/27 34/29/27
Standard static pressure Pa 50 50
Max. static pressure Pa 200 200
Indoor air ow (H/M/L) m
3
/h 500/410/360 600/510/450
Air outlet dimensions mm 247*174*2 247*174*2
Air return dimensions mm 660*200 660*200
Dimension (W*H*D) mm 750/635/280 750/635/280
Packing (W*H*D) mm 980/740/335 980/740/335
Net weight kg 29 29
Gross weight kg 35 35
Nominal condition: indoor temperature (cooling): 27DB (°C)/19WB (°C), indoor temperature (heating): 20DB (°C)
Outdoor temperature (cooling): 35DB (°C)/24WB (°C), outdoor temperature (heating): 7DB (°C)/6WB (°C)
The noise level will be measured in the third octave band limited values, using a Real Time Analyser calibrated
sound intensity meter. It is a sound pressure noise level.
