363
Constant Air Volume Duct
Type Indoor Unit (AD*MQERA)
MODEL AD182MQERA AD242MQERA
Cabinet
Cabinet Coating Type Plastic Plastic
Cabinet Salt Spray Test
Duration
Hour 48 48
Control Box IP Class I I
Construction
Sheet Metal Thickness 1.2 1.2
Drain Pan Material EPS EPS
Drain Pan Insulation HF-1 HF-1
Drain Pump Option mm 600 600
Branch Outlet Option NO NO
Indoor Wall
Material Hot zinc plate Hot zinc plate
Thickness mm 1.2 1.2
Double or Single Skin Single Single
Air Filter
Material PP PP
Mesh 100 100
Pressure Drop Pa 5 5
Piping
dimension
Liquid pipe mm 6.35 9.52
Gas pipe mm 12.7 15.88
Drain hose mm 31.5 31.5
Fresh air dimension mm Ø170 Ø170
Sound pressure level (H/M/L) dB(A) 32/29/26 33/29/25
Sound power level (H/M/L) dB(A) 36/33/30 37/33/29
Standard static pressure Pa 50 50
Max. static pressure Pa 200 200
Indoor air ow (H/M/L) m
3
/h 900/780/600 1100/1020/920
Air outlet dimensions mm 247*174*2 247174*3
Air return dimensions mm 660*200 740*200
Dimension (W*H*D) mm 750/635/280 950/635/280
Packing (W*H*D) mm 980/740/335 1180/740/335
Net weight kg 29 34
Gross weight kg 35 41
Nominal condition: indoor temperature (cooling): 27DB (°C)/19WB (°C), indoor temperature (heating): 20DB (°C)
Outdoor temperature (cooling): 35DB (°C)/24WB (°C), outdoor temperature (heating): 7DB (°C)/6WB (°C)
The noise level will be measured in the third octave band limited values, using a Real Time Analyser calibrated
sound intensity meter. It is a sound pressure noise level.
