422
White
BlueBlue
One side of
control cabinet
One side of blower
Connector,
white
White
Blue
White
Red
High-speed blowing wind
Standard blowing wind (at delivery)
One side of blower
Standard static pressure Maximal static pressure
100 196 AD302-482MHERA
4. Drainpipe
(a) Keep a gradient (1/50-1/100) of the drainpipes and avoid lobbing or curving.
(b) When connecting the drainpipe to the equipment, don't apply too much force on one side of the equipment.
Meanwhile, the piping should be positioned as close to the equipment as possible.
(c) For the drainpipe, the general purpose hard PVC tube can be purchased at local shops. During the connection,
insert the end of PVC tube into the wash port and fasten it with drainage hose and thread clip. Binding agents
shouldn't be used to connect the wash port and drainage hose.
(d) When the laid drain piping is used for multiple equipments, the public
piping should be lower about 100mm than the wash ports of equipments, as
shown in the gure.
Thicker pipes should be used for this application.
■ Proper Piping ■ Improper Piping
A
A
A
G
H
H
D
G
Wash port
Master unit
Drainage hose
Thread clip
(accessory)
Binding
S
E
S
H
S
J
Wash port
Drainage hose
Super high-speed blowing wind
White
Red
One side of blower
Black
Blue
Red
Blue
Black
Blue
Blue
Black
White
Blue
Brown
White
Red
Black
