C Smart Air Flow
Cassette Type Indoor Unit
Model AB072MRERA AB092MRERA AB122MRERA
Cabinet
Cabinet coating
type
Galvanized Galvanized Galvanized
Cabinet salt spray
test duration
Hour 100 100 100
Control box IP class IP40 IP40 IP40
Construction
Sheet metal
thickness
0.8 0.8 0.8
Drain pan material PS PS PS
Drain pan insulation 20 20 20
Drain pump option Standard 1200mm Standard 1200mm Standard 1200mm
Branch outlet option No No No
Indoor wall
Material Hot zinc plate Hot zinc plate Hot zinc plate
Thickness mm 0.8 0.8 0.8
Double or single
skin
Single Single Single
Air lter
Material PP PP PP
Mesh 100 100 100
Pressure drop Pa 5 5 5
Piping
dimension
Liquid pipe mm 6.35 6.35 6.35
Gas pipe mm 9.52 9.52 12.7
Drain hose mm Φ25 Φ25 Φ25
Panel
Model PB-950KC PB-950KC PB-950KC
Dimension mm 950/950/50 950/950/50 950/950/50
Packing mm 1013/1025/123 1013/1025/123 1013/1025/123
Net weight kg 6.5 6.5 6.5
Gross weight kg 9 9 9
Fresh air dimension mm / / /
Sound pressure level (H/M/L) dB(A) 30/27/25 30/27/25 30/27/25
Sound power level (H/M/L) dB(A) 44/41/39 44/41/39 44/41/39
Standard static pressure Pa 0 0 0
Indoor air ow (H/M/L) m
3
/h 1000/810/620 1000/810/620 1000/810/620
Dimension (W*H*D) mm 840/840/183 840/840/183 840/840/183
Packing (W*H*D) mm 983/983/268 983/983/268 983/983/268
Net weight kg 28 28 28
Gross weight kg 31 31 31
Norminal condition: indoor temperature (cooling): 27°C DB/19°C WB, indoor temperature (heating): 20°C DB
Outdoor temperature (cooling): 35°C DB/24°C WB, outdoor temperature (heating): 7°C DB/6°C WB. The noise
level will be measured in the third octave band limited values, using a Real Time Analyser calibrated sound
intensity meter. It is a sound pressure noise level.
