459
Built-in Floor Standing
Type Indoor Unit
MODEL AE162MLERA AE182MLERA AE242MLERA
Cabinet
Cabinet coating type / / /
Cabinet salt spray test duration Hour / / /
Control box IP class / / /
Construction
Sheet metal thickness 0.8/1.0/1.5 0.8/1.0/1.5 0.8/1.0/1.5
Drain pan material / / /
Drain pan insulation / / /
Drain pump option No No No
Branch outlet option / / /
Indoor wall
Material Hot zinc plate Hot zinc plate Hot zinc plate
Thickness mm 0.8/1.0/1.5 0.8/1.0/1.5 0.8/1.0/1.5
Double or single skin Single Single Single
Air lter
Material PP PP PP
Mesh 100 100 100
Pressure drop Pa 30 30 30
Piping
dimension
Liquid pipe mm 6.35 6.35 9.52
Gas pipe mm 12.7 12.7 15.88
Drain hose mm 20 20 20
Fresh air dimension mm / / /
Sound pressure level (H/M/L) dB(A) 40/37/35 42/39/36 42/39/36
Sound power level (H/M/L) dB(A) 53/50/48 55/52/49 55/52/49
Standard static pressure Pa 0 0 0
Max. static pressure Pa 30 30 30
Indoor air ow (H/M/L) m
3
/h 950/830/720 950/830/720 950/830/720
Air outlet dimensions mm 780*118 780*118 780*118
Air return dimensions mm 946*190 946*190 946*190
Dimension (W*H*D) mm 1116*624*221 1116*624*221 1116*624*221
Packing (W*H*D) mm 1425*685*315 1425*685*315 1425*685*315
Net weight kg 31 31 31
Gross weight kg 39 39 39
Nominal condition: indoor temperature (cooling): 27DB (°C)/19WB (°C), indoor temperature (heating): 20DB (°C)
Outdoor temperature (cooling): 35DB (°C)/24WB (°C), outdoor temperature (heating): 7DB (°C)/6WB (°C)
The noise level will be measured in the third octave band limited values, using a Real Time Analyser calibrated
sound intensity meter. It is a sound pressure noise level.
