565
HRV
22.8.2 Installing Heat Reclaim Ventilation
Do not install the unit in:
Preparation Prior to Installation
■ Places close to high temperature locations or naked res; otherwise, re accident or overheating may occur.
■ Places where oil mist or gasoline exists, such as kitchen; otherwise, re may occur.
■ Places where poisonous gases or corrosive material (acid and alkali solvents) are to be found, such as
machine shop and chemical plant. Places where leakage of inammable gases is possible shall also be
avoided.
■ Places with high humidity, such as bathroom, where electric shock or creepage and other troubles may take
place.
■ Places close to machines sending out electromagnetic waves, which may interrupt the operation of control
system and cause failure.
Please make sure that temperature and humidity in places where air inlet and outlet grille is installed are controlled
within prescribed range under operating conditions. Do not install the grille in refrigerator vehicle, low temperature
places or warm water swimming pool; otherwise, short circuit or re may ensue. Vehicles or vessels shall also be
avoided.
Concerned specialists shall teach users how to correctly operate the unit with aid from the manual (especially air
screen service and operation procedures).
3. Special attention shall be given to following issues during installation and following completion of the same
a. Check upon Construction Completion
Accessories and ttings necessary for installation shall be kept and must not be discarded!
2. Accessories: Other parts not shown below shall be prepared by users.
1. Transporting the Unit
Decide on transporting route and do not unpack before arriving at installation site.
When unpacking is compulsory, please use soft rope or adopt the "rope plus angle of protection" approach to
lifting devices so that scufng or damages can be avoided.
When moving unpacked units, lift the unit by hoist hook, and not by any other objects on the unit (air hose joints
in particular).
Designation
Appearance
Number
4 16
2
1
Air hose joint ange M4 tapping screw Lace
Manual
CATUION
CATUION
Installation Procedures
To Next Page
