48
Subject to change without notice
5.8.6 “Message” window control functions.
The “STOP” button in the message window stops the pro-
gram execution sequence e.g. for repair work. The ESC key
on the keyboard has the same function. If after repair work
the program is to be continued, set the arrow e.g. 10 steps
back (to check if the problem has been solved) and start
the program by clicking “sequence”.
“NEXT” continues the program. The ENTER and SPACE key
on the keyboard have the same function.
If a step in the program sequence is to be repeated, click
the button between NEXT and STOP. The keyboard keys
“W” and “G” have the same effect.
If text and a photo are displayed, pressing the keyboard key
“Z” toggles between a zoomed and normal photo display.
With the keys “P” or “B” choose whether the photo or text
is shown in the foreground.
5.8.7 “step label”
Opens a selection box with PSH adjustments/checks. Af-
ter selecting an item (e.g. Y GAIN check CH1) the arrow is
automatically set to the line where an adjustment/check
must be started after changes have been made (repair or
adjustment) regarding this item. Then “sequence” must be
clicked to continue the adjustment/check from this item
until the end of the program is reached. That makes sure
that other adjustments - based on the repair or adjustment
– are checked and if required corrected.
5.8.8 “DB repair” (not available in the service version)
Please follow the instruction in the window which opens.
5.8.9 “< B” (back) and “> F” (forward) buttons.
These buttons enable to select a program line.
5.8.10 “sequence”
If program parts at the beginning shall not be executed, click
in the fi rst column to determine the step number where the
program is started, or use the function described under
item 5.8.8. Thereafter click “sequence” to start the program
at the determined line.
5.8.11 “stop” button in the “program step listings” window.
Finishes the program execution if being clicked long. This
function is for interruption of automatic adjustments when
due to an error an endless loop is present.
5.8.12 “single command”
Executes the activated program step.
5.8.13 Fail/Pass window.
Shows the adjustment/check result.
5.8.14 “delay in ms”
Shows the execution time setting for each program line
(default 300 ms). If a PC with less performance is used,
it might be to mark the setting by aid of the mouse and to
input a higher delay time value.
HM1X0X Oscilloscopes Test and Adjustment
