Panel Saw
K3 basic/K3 winner
Making adjustments and preparations
8.8.2 Prepare the machine to operate
1. Slide the sliding table to the right until it reaches its
limit.
2. Slide the sliding table to the left until it reaches its
limit.
! Sliding cover
" Sliding table
Fig. 52: Prepare the machine to operate
Fig. 53: Prepare the machine to operate
3. Push the lock to the top.
4. Switch on the machine.
! Safety system
8.9 Saw blade
8.9.1 Tools
Warning! Risk of injury!
Only use saw blades ,
• which have an authorised speed higher than the
speed of the saw arbor,
• which conform to DIN EN 847-1 standards and
• which are marked with „MAN“!
Only use original HAMMER tools (HAMMER-catalogue).
Only the following tools are allowed:
Circular saw blades
Diameter 250 bis 315 mm
Chisel, without driver 30 mm
Speed (50 Hz) 4800 min-1
Cutting height max. 103 mm
Saw blade tiltable from 90 to 45°
