Hantek 6022BE - The Display System

Hantek 6022BE
The display System
Click “Display” in main menu
The following figure shows the display system menu. It shows the display
parameters setting.
 Type
 Grid
 Intensity
Display type
Click “Type” in “Display” menu.
The following figure shows the type parameters setting.
If the Vectors type mode is selected, the waveform will be displayed as
following figure.
46
The User’s Manual
