Page #102 background imageLoading...
Page #102 background image
Specifications
DSO8000E Series HandHeld Oscilloscope User Manual 97
Inputs
Input Coupling
DC, AC or GND
Input Impedance,
DC coupled
1MΩ±2% in parallel with 20pF±3pF
Probe Attenuation
1X, 10X
Supported Probe
Attenuation
Factors
1X, 10X, 100X, 1000X
Maximum Input
Voltage
Overvoltage Category
Maximum Voltage
CAT I and CAT II
300V
RMS
(10×), Installation Category
CAT III
150V
RMS
(1×)
Measurements
Cursors
Voltage difference between cursors: V
Time difference between cursors: T
Reciprocal of T in Hertz (1/ΔT)
Automatic
Measurements
Frequency, Period, Mean, Peak-to-peak, Cycle RMS, PRMS, Minimum,
Maximum, Rise Time, Fall Time, + Width, - Width, + Duty, - Duty, Base,
Top, Middle, Amplitude, Overshoot, Preshoot, Pmean, FOVShoot,
RPREShoot, BWidth, Delay 1-2 , Delay 1-2 , LFF, LFR, LRF, LRR,
FFR, EFRF
General Specifications
Display
Display Type
5.6 Inch width TFT Display
Display Resolution
480 (Vertical) X 640 (Horizontal) pixels
Display Contrast
Adjustable (16 gears) with the progress bar
Probe Compensator Output
Output Voltage,
typical
About 2Vpp into ≥1MΩ load
Frequency, typical
1kHz
Power Supply
Switching Adatper
AC Input:100-240VAC
RMS
,1.5A
MAX,50Hz/60Hz; DC Output:12V,
3000mA
Power Consumption
<30W
Battery
3.7V 2600mAH standard 18650 cylindrical Lithium-ion Battery x 6pcs
Environmental
Temperature
Operating: 32 to 122 (0 to 50)
Nonoperating: -40 to 159.8 (-40 to +71)
Humidity
+104 or below (+40 or below): ≤90% relative humidity
106 to 122 (+41 to 50): ≤60% relative humidity
Altitude
3,000m (10,000 feet)
Mechanical
