Hantek DSO8000E Series User Manual

Specifications
DSO8000E Series HandHeld Oscilloscope User Manual 98
Size
260 x 220 x 75(mm)
Weight
2.5 Kg
Waveform Generator
Frenquency Range
Sine: 1Hz(DC)~30MHz
Ramp: 1Hz~10MHz
Square: 1Hz~5MHz
Trapezia: 1Hz~3MHz
Exponent: 1Hz~60KHz
AM/FM: 1Hz~10MHz
Arb: 1Hz~25MHz
DAC Clock
2K~200MHz adjustable
Memory Depth
4KSa
Vertical Resolution
12 Bits
Stability
<30ppm
Amplitude
±3.5V Max.
Output Impedance
50 Ω
Output Current
50mA Ipeak=50mA
System Bandwidth
25M
Harmonic Wave Distortion
-50dBc(1KHz), -40dBc(10KHz)
Meter Mode
Maximum Resolution
6000 Counts
DMM Testing Modes
Voltage, Current, Resistance, Capacitance, Diode & Continuity
Maximum Input Voltage
AC: 600V DC: 600V
Maximum Input Current
AC: 10A DC: 10A
Input Impedance
10MΩ
Meter Specification
Range
Accuracy
Resolution
DC Voltage
60.00mV(manual)
±1%±3digit
10uV
600.0mV
100uV
6.000V
1mV
60.00V
10mV
600.0V
100mV
600V
1V
AC Voltage
60.00mV(manual)
±1%±3digit
10uV
600.0mV(manual)
100uV
6.000V
1mV
60.00V
10mV
600.0V
100mV
DC Current
60.00mA
±1%±5digit
10uA
