Programmable Temperature & Humidity Controller
18
Function setting
② ③①
⑤④ ⑥ ⑦
No. Name Description
1 Run screen Go to operation screen[Constant-value/Program].
2 Function Go to operation setting screen.
3 PV graph view Go to saved PV graph screen.
4 Program Go to program setting(pattern setting, graph, etc.) screen.
5 Date / Time Go to current time and schedule setting screen.
6 Event Go to event and error history screen.
7 System menu Go to system setting[sensor input, control output, and PID] screen.
Fig. 8) Main menu
If you press after gIvIng power the screen below appears
