1. Installation site & cautions
2. How to install
● It may cause electric shock so install in on the panel first.
● Avoid following locations.
• Where people might unintentionally contact a terminal
• Where there is strong vibration, impact, or electromagnetic field
• Where it is exposed to a corrosive or inflammable gas
• Where the temperature changes sharply or there is much humid, dust, or salt
• Where it is directly exposed to direct sunlight or the temperature is extreme
• places with combustibles and flammable objects
● The case and front section are made of fire-retardant polycarbonate but do not install the product
directly on a flammable object.
● Keep away any device or wire that may cause noise. Enough preheating is required especially under
0℃. Keep away any heat-radiating device.
● For wiring, disconnect the entire power.
● This product works at 100 - 240 V a.c. / 50 - 60 ㎐ without special setting. Please make sure that
the power is within the rating to avoid any product damage leading to fire or electric shock.
● Do not touch it with wet hand. You may be electrically shocked.
● Follow conventional cautions in order to reduce the risk of fire, electric shock, and injury.
● For grounding, refer to how to install. (Grounding resistance : 100 Ω or less)
● Keep ventilation and the radiating hole free.
● The overvoltage protection degree is Category II(IEC 60664-1) and the usage environment is Pollution
Degree II.
● Do not use sharp objects or excessive force when operating the touch screen
● The external terminals(sensor input, communication, and control output terminals) must be connected
to separate circuits with at least reinforced insulation from dangerous voltage sections.
● To disconnect the main power, install a switch or circuit breaker.
●
Use 2-5mm thick panels.
●
Insert this device from the front of panel.
●
Connect dedicated clamps to the clamping grooves and fix them with bolts.
(Before fully tightening the clamps, position them in place).
Installation
Before installing it, disconnect the power. Do not touch a terminal because it may lead to
electric shock.
Danger
