Programmable Temperature & Humidity Controller
6
Fig. 1) How to install the panel
▶Display
(1) How to install the panel
(2) How to install VESA mount
+
1
2
3
4
5
-
DC 5V
6
7
8
COM1
COM2
75.0
75.0
4-M4
Connect an M4 X 7L bolt into a VESA hole.
The tightening torque must be 0.5 N·m or less for clamping.
Forcible tightening may lead to deformation or damage.
