43
Before starting Installation
Operation
Screen block
diagram
Function setting Program System setting Specifications
●
Wait operation
Wait operation
Wait time
Wait range
Wait operation is
cancelled because PV
is within defined wait range
Wait operation is
started because
PV is out of
defined wait range
SEG. progress
without wait mode
SEG progress
with wait mode
SEG. progress
without wait mode
SEG progress
with wait mode
Wait time
setting
Wait operation
Wait range
Wait operation is
started because
PV is out of
defined wait range
Wait operation is
cancelled because
PV is within defined
wait range
Wait operation
Wait time
Wait range
Wait operation is
cancelled because PV
is within defined wait range
Wait operation is
started because
PV is out of
defined wait range
SEG. progress
without wait mode
SEG progress
with wait mode
SEG. progress
without wait mode
SEG progress
with wait mode
Wait time
setting
Wait operation
Wait range
Wait operation is
started because
PV is out of
defined wait range
Wait operation is
cancelled because
PV is within defined
wait range
If measurement (PV) is out of wait range,
it waits until the measurement(PV) enters
the wait range for defined wait time.
If wait time is elapsed, it moves to next segment
even though measurement(PV) is out of wait
range.
●
Operation start mode
SV setting value
SV setting value
PV measurement
PV measurement
Start of program operation Start of program operation
▶ Part repetition
Part repetition: total 6 per pattern setting possible, from n.1 in order progression.
1) Set the start segment number. If set 0, execute from next part repetition
2) Set the stop segment number. If set 0, execute from next part repetition
3) Set the part repetition count
[Part repetition Parameter]
Parameter Setting range Default
Start segment 0 ~ 100 SEG 0
Stop segment 0 ~ 100 SEG 0
Part repetition 0 ~ 99 0
Fig. 51) Part repetition
