3
Before starting
Installation
Operation
Screen block
diagram
Function setting Program System setting Specifications
3
▶ Suffix code
Model Code Description
TH510- ☐ ☐ ☐
Programmable temperature/Humidity controller
Display
1 Display(5.7" TFT LCD)
N None
Input/output
1
8 input points/6 output points(1 module)+Power module
+Control module
2
8 input points/14 output points(2 modules)+Power module
+Control module
3
16 input points/16 output points(3 modules)+Power module
+Control module
N No input/output
Language
S Korean, English, and Chinese(Simplified)
T Korean, English, and Chinese(Traditional)
※ This product consists of the display and control(power, control, input, and output modules).
(Up to 32 contact input/output points, respectively)
▶ Components
Product Model Description
Display TH510-1N☐ Display(5.7" TFT LCD)
Control module TH510-MAIN Temperature
•
Humidity control module
Power module TM-PWR Power module
Input module TM-DI Module with 16 input points
Output module TM-DO Module with 8 output points
Input/output module TM-DIO Module with 8 input and 6 output points
