Programmable Temperature & Humidity Controller
80
▶ Output specifications
▶ Contact input
▶ Communication specifications
Contact output(DO) Up to 32 relay
A
Contact
30 V DC 3 A max, 250 V AC 3 A
B
Contact
NO : 30 V d.c. 5 A max, 250 V AC 5 A
Control output
SSR
output
ON : 18 V DC Pulse voltage(800 Ω or more load resistance)
SCR
output
4 - 20 mA DC (
600 Ω or less load resistance
)
Transmission output
Current output
4 - 20 mA DC
Load resistance 600 Ω or less load resistance
Output limit
-5.00 - 105.00 %
Output type
Specific value(PV), Setting value(SV), Output(MV), and random
Refresh interval
250 ms
Max. number of input 32 Contacts
Input type No-voltage contact input
ON/OFF sensing resistor Minimum 1㏀ and less: On, maximum 10㏀ and more: Off recognition
Min. sensing time 0.25 sec
Operational conditions During operation/Always
Contact function Operation and stop/hold/step by DI ; User can define error screen.
Applied standard RS485
Max. connection number 1:32 (address 1 ~ 99)
Communication type 2-wire
Synchronization Asynchronous
Communication distance Approx. 1.2 km or less
Communication speed 9600, 19200, 38400, 57600, 115200 bps
Data Length 7/8 bits
Parity Bit NONE / EVEN / ODD
Stop Bit 1/2 bit(s)
Protocol PC-Link / PC-Link+SUM / MODBUS ASC / MODBUS RTU
Response Time
0 - 100 ms
