HARDI CONTROLLER 5500
Contents: XXXX L
Filled: XXXX L
1.2.2
FILL LEVEL:
Limit: XXXX L
Tank contents optionsTank contents options
Tank contents optionsTank contents options
Tank contents options
The sprayer may be fitted with a filling meter or tank contents transducer.
This measures the volume passing to the tank. It sounds an alarm when the
programmed volume is filled and the valve must be closed.
It may also be fitted with a shut-off on the filling line. This automatically
closes when the programmed volume is filled.
The transducer and shut-off valve type fitted has to be activated from the
Extended menu at installation. The HARDI Service centre does this.
Menu [1.2.1 Tank contents]Menu [1.2.1 Tank contents]
Menu [1.2.1 Tank contents]Menu [1.2.1 Tank contents]
Menu [1.2.1 Tank contents]
Shortcut
Press and hold until menu [1.2.1 Tank contents] is shown.
Press to set maximum tank contents.
Press to confirm.
The filling volume can be changed in menu [1.2.2].
Menu [1.2.2 Fill meter] (optional)Menu [1.2.2 Fill meter] (optional)
Menu [1.2.2 Fill meter] (optional)Menu [1.2.2 Fill meter] (optional)
Menu [1.2.2 Fill meter] (optional)
Press for maximum tank contents.
Press to clear or…
Press or for other value.
Press .
Actual contents and volume filled will be shown. The audio alarm will sound
and the 3
rd
line will blink when the limit is reached.
