16.2 Guidelines and manufacturer’s declaration – electromagnetic interference immunity
Electromagnetic
interference immunity
tests
IEC60601- TestLevel Compliance Level Electromagnetic
Environment - Guidelines
Electrostatic discharge
(ESD) in accordance
with IEC61000-4-2
± 8kV contact
discharge
± 2kV, ± 4kV,
± 8kV, ± 15kV
air discharge
as test level Floors should be made of wood or
concrete or covered with ceramic
tiles� If the floor has a synthetic
material covering, the relative
humidity must be at least 30%�
Rapid transient
electrical
interference/ bursts
in accordance with
IEC61000-4-4
± 2kV for power
supply cables
± 1kV for input and
output cables
± 2kV for power
supply cables
(power supply)
not applicable
The quality of the supply voltage
should be that of a typical business
or hospital environment, e�g�
according to EN50160�
Surge voltages
(surges) in accordance
with IEC61000-4-5
± 1kV normal mode
voltage
± 2kV common mode
voltage
± 1kV normal mode
voltage
± 2kV common mode
voltage,
not applicable
The quality of the supply voltage
should be that of a typical business
or hospital environment,
e�g� according to EN50160�
Magnetic field at
supply frequency
(50 / 60 Hz) in
accordance with
IEC61000-4-8
30A/m
50 or 60Hz
30A/m
50 and 60Hz
Magnetic fields at mains frequency
should correspond to the typical
values found in a business or
hospital environment�
Voltage drops, brief
interruptions and
fluctuations in the
supply voltage in
accordance with
IEC61000-4-11
0 % U
T
(100 % drop
in U
T
) for 0�5cycles;
0°, 45°, 90°, 135°,
180°, 225°, 270°, 315°�
0 % U
T
(100 % drop in
U
T
) for 1 cycle�
70 % U
T
(30 % drop in
U
T
) for 25/30cycles
0 % U
T
(100 % drop in
U
T
) for 5s
as test value The quality of the supply voltage
should be that of a typical business
or hospital environment�
If the user of the VivanoTecPro
negative pressure unit requires
continuous functioning even in the
event of interruptions to the power
supply, it is recommended to supply
the VivanoTecPro negative pressure
unit through an uninterruptible
power supply or a battery�
