Hasselblad X1D User Manual

X1D www.hasselblad.com
USER GUIDE
10
Introduction
1.4 X1D TECHNICAL SPECIFICATIONS
Camera Type Medium Format Mirrorless Digital camera with Autofocus, Auto exposure, interchangeable Lenses.
Construction Machined aluminium. Tripod socket 1/4”
Sensor Type CMOS, 50 mega pixels (8272 × 6200 pixels, 5.3 × 5.3 µm)
Sensor Dimensions 43.8 × 32.9mm
Image Size Stills: RAW 3FR capture 65MB on average. TIFF 8 bit: 154MB; Video: HD (1920 x 1080p)
File Format
Stills: Hasselblad 3FR
Video: H.264 Compressed (25 fps)
Shooting Mode Single shot stills, Video
Colour Denition 16 bit; Dynamic range approx. 14 stops
ISO Speed Range ISO Auto, 100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Storage Options Two SD cards or tethered to Mac or PC
Colour Management Hasselblad Natural Colour Solution, HNCS
Storage Capacity 16GB card holds 240 images on average
Capture Rate TBD
User Interface
Touch functionality: Yes, full support. Touch interface including swipe, scroll and pinch/spread to zoom. Camera grip with buttons and
control wheels. Many camera functions and settings can be controlled from a tethered computer or iPhone/iPad over Wi-Fi.
Display 3 inch TFT type, 24 bit colour, 920K pixels.
Live View On camera, host and iOS device with high frame rate.
Viewnder (EVF) 2.4 Mega-pixel Electronic Viewnder (EVF)
Histogram Feedback Yes, on rear display
IR Filter Mounted in front of sensor
Software Phocus for Mac and Windows. Compatible with Adobe Camera and Adobe Photoshop Lightroom.
Platform Support Macintosh: OS X version 10.9; PC: XP/Vista/Windows 7 (32 and 64 bit)/ 8 / 10
Host Connection Type USB 3.0 (5 Gbit/s) Type-C connector
Additional Connections Mini HDMI, Audio In/Out
Operating Temperature -10 - 45 ˚C / 14 - 113 ˚F
Wi-Fi 802.11 b, g, n, a, ac (a and ac depending on region)
Dimensions Complete camera w/ XCD 45mm lens: 148 x 97 x 125mm [W x H x D]
Weight 1170 g (Complete camera w/ XCD 45mm lens, Li-Ion battery and card)
Lenses
Hasselblad XCD lenses with built in electronically controlled shutter and aperture. Automatic or manual focusing with instant manual
focus override. All HC/HCD lenses can be used with an adapter (optional). Lens shades can be mounted in reverse for transport.
Shutter Electronically controlled lens shutter with speeds up to 1/2000. Flash sync at all speeds.
Shutter Speed Range 60 minutes to 1/2000 sec with XCD lenses. 1/800 or 1/2000 with HC/HCD lenses.
Flash Sync Speed Flash can be used at all shutter speeds.
Flash Control
TTL centre weighted system. Compatible with Nikon
TM
System ashes. ISO range 100 to 6400. Flash output can be adjusted (-3 to
+3EV) for ll-in purposes independent of ambient light. Sync at all shutter speeds.
Flash Compatibility In TTL-mode the following Nikon Flash products can be used: SB-300, SB-500, SB-700, SB-900, SB-910
Focusing
Automatic and manual focusing. Instant manual focus override. Automatic focusing using contrast detection. 100% zoom possible in
manual focus.
Exposure Metering
Spot, Centre Weighted and Centre Spot
Metering range Spot: EV2 to 21, Centre Weighted: EV1 to 21, Centre Spot: EV1 to 21
Power Supply Rechargeable Li-ion battery (7.2 VDC/3200 mAh)
Customization Some of the X1D’s functions can be customized by the user to suit specic styles or situations through the built-in menu system.

Hasselblad X1D Specifications

General

Megapixel	50 MP
Camera type	MILC
Image stabilizer	-
Image sensor size	- \
Image formats supported	JPEG
Maximum image resolution	8272 x 6200 pixels
Image sensor size (W x H)	43.8 x 32.9 mm
Still image resolution(s)	8272 x 6200
Optical zoom	- x
Focus	TTL
Focus adjustment	Auto/Manual
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 12800, 25600
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	60 s
Video recording	Yes
Maximum video resolution	1920 x 1080 pixels
Memory slots	2
Compatible memory cards	SD
Maximum memory card size	16 GB
Flip-out screen	No
Display diagonal	3 \
Display resolution (numeric)	920000 pixels
Viewfinder type	Electronic
USB version	3.2 Gen 1 (3.1 Gen 1)
HDMI connector type	Mini
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Self-timer delay	- s
Product color	Black, Grey
Power source type	Battery
Battery voltage	7.2 V
Battery capacity	3200 mAh

Weight and Dimensions

Depth	98 mm
Width	150 mm
Height	71 mm
Weight	725 g
