ATTACH THE LENS
Caution!
Be careful when you attach/detach the components to/from
the camera. This will help prevent damage to the data bus
connections.
Caution!
Do not insert ngers into the camera body. This can cause
damage to the equipment.
1 Push the lens removal button (A) and remove protection
cover lid (B) from the camera body.
2 Rotate the lens so that the red mark on the lens (C) lines up
with the red mark (D) on the camera body.
3 Mount the lens (E) into the camera body (F) and then turn
the lens clockwise to lock its position.
4 Make sure the lens is locked to the camera body before
using or moving the camera.
A
B
C
D
E
F
X1D www.hasselblad.com
USER GUIDE
51
