3.15 REMOVE AND ATTACH A LENS
REMOVE THE LENS
Caution!
Be careful when you attach/remove the components to/from
the camera. This will help prevent damage to the data bus
connections.
Caution!
Do not insert ngers into the camera body. This can cause
damage to the equipment.
1 Hold the lens (C) with one hand and hold the camera body
(A) still.
2 Push the lens removal button (B).
3 Rotate the lens counter clockwise.
4 Push the lens (C) away from the camera body.
5 Attach the protection cover lid (D) on the camera body
directly.
6 Attach a lens protection lid on the detached lens to prevent
damage.
7 Store the lens with both lens protection lids on and the lens
hood inverted over the lens instead of in front of the lens.
A
B
C
D
X1D www.hasselblad.com
USER GUIDE
50
