Initiation
Initial operation of Laser Aligner requires following measures:
Mounting of rolls and scale holding device on mobile instrument cabinet.
Fit in fastening screws M8 x 65 from top and tighten
with nut and washer.
For each roll
4 x Carriage bolt M8
4 x Washer M8
4 x Nut M8
3 x Carriage bolt M8 x 30
3
x Washer M8
3 x
Nut M8
