Wheel Alignment AXIS500
AXIS500 Manual Instructions
Front Wheel Alignment
5.5 Check of Steering Wheel Center Position
• Check the steering wheel center position
at the steering box.
• If the mark at the steering box is off-
center, the drug link has to be adjusted
until both marks are in alignment. (box
neutral position).
Important:
The position of the two laser points on the
magnetic scales must change. Adjust, if
necessary.
(Illustration 11)
