Wheel Alignment AXIS500
AXIS500 Manual Instructions
3.1 Agreed functionality
• Laser Aligner AXIS500 is designed for wheel alignment of motor vehicles.
• Only for the fast measurement of the chassis geometry.
Front wheel alignment and steering axle:
- Total Toe / Single Toe
- Camber
- Caster
- KPI
- Relative steering angle
- Steering wheel centre position
Rear wheel alignment:
- Toe
- Camber
- Offset
- Out of square
• Laser Aligner AXIS500 enables measurements while in driven position. No lifting of
vehicle is required.
• Measurements can be taken fast and reliable on all types of motor vehicles ( with
specific accessories provided).
Safe operation of Laser Aligner AXIS500 cannot be ensured
if not used appropriately to its agreed functionality!
The operator-and not the manufacturer- is responsible for all
damages and injuries resulting from inappropriate use to its
agreed functionality.
Applied laser of laser measuring head is a class 2 laser. Short-
term laser beam impact ( up to 0,25 s) proves not to be harmful to
human eyes. Eye blink reflex prevents the eye from injury during
short-term, unintentional exposure to laser beam.
DO NEVER LOOK INTENTIONALLY INTO LASER BEAM!
In case of suspected eye injury through laser beam impact consult a ophthalmologist
immediately!
