3.5 Technical Data
Measuring Accuracy:
Toe < 0,5 mm
Camber
Caster
Steering
Relative steering angle +/- 15 min.
Axle mismatch +/- 1 mm
Axle torsion +/- 5 min.
Toe measurement range +/- 28 mm
Camber measurement range to 5 degrees
KPI measurement range to 18 degrees
Castor measurement range to 12 degrees
Turning plate carrying capacity 6 t / piece
Laser:
Model LG650-7 (80)
Operating voltage 3 Volt (2 x Mignon Typ AA 1,5 Volt)
Power P
o
0,91 mW
Wave range
λ
650 nm
Range 20 m
Laser class 2 DIN EN 60825-1:1994-07
Electronic inclinometer:
Operating voltage 6 volt (4 x Mignon Type AA Batteries 1.5 volt)
Current input during operation 10 mA (without lighting), 60 mA (with lighting)
Closed-circuit current (unit switched off) < 10 µA
Running time with one set of batteries without lighting: approx. 50 - 60 h.
with lighting: approx. 30 h.
Specified measuring range +/- 45° for both axles
Extended measuring range +/- 90° for both axles
Accuracy of the specified measuring range 0... 10°: +/-0° 03’
10 ... 45°: +/-0° 12’
Resolution 0° 01’
Temperature range -5 to +50 °C (in use) -20 to 65 °C (storage)
Shock resistance of the sensor 3.500g
0 ... 10°: +/- 0° 03’
10 ... 45°: +/- 0° 12’
