Wheel Alignment AXIS500
AXIS500 Manual Instructions
44
Annex
Conversion Table from Millimetres into Degrees
Toe in
mm
W h e e l S i z e
19,5“
20“
22“
22,5“
24“
24,5“
0,5
0° 03' 0° 03' 0° 03' 0° 03' 0° 03' 0° 03'
1,0
0° 07' 0° 07' 0° 06' 0° 06' 0° 06' 0° 06'
1,5
0° 10' 0° 10' 0° 09' 0° 09' 0° 08' 0° 08'
2,0
0° 14' 0° 14' 0° 12' 0° 12' 0° 11' 0° 11'
2,5
0° 17' 0° 17' 0° 15' 0° 15' 0° 14' 0° 14'
3,0
0° 21' 0° 20' 0° 18' 0° 18' 0° 17' 0° 17'
3,5
0° 24' 0° 24' 0° 22' 0° 21' 0° 20' 0° 19'
4,0
0° 28' 0° 27' 0° 25' 0° 24' 0° 23' 0° 22'
4,5
0° 31' 0° 30' 0° 28' 0° 27' 0° 25' 0° 25'
5,0
0° 35' 0° 34' 0° 31' 0° 30' 0° 28' 0° 28'
5,5
0° 38' 0° 37' 0° 34' 0° 33' 0° 31' 0° 30'
6,0
0° 42' 0° 41' 0° 37' 0° 36' 0° 34' 0° 33'
6,5
0° 45' 0° 44' 0° 40' 0° 39' 0° 37' 0° 36'
7,0
0° 49' 0° 47' 0° 43' 0° 42' 0° 39' 0° 39'
7,5
0° 52' 0° 51' 0° 46' 0° 45' 0° 42' 0° 41'
8,0
0° 56' 0° 54' 0° 49' 0° 48' 0° 45' 0° 44'
8,5
0° 59' 0° 58' 0° 52' 0° 51' 0° 48' 0° 47'
9,0
1° 02' 1° 01' 0° 55' 0° 54' 0° 51' 0° 50'
9,5
1° 06' 1° 04' 0° 58' 0° 57' 0° 54' 0° 52'
10,0
1° 09' 1° 08' 1° 02' 1° 00' 0° 56' 0° 55'
10,5
1° 13' 1° 11' 1° 05' 1° 03' 0° 59' 0° 58'
11,0
1° 16' 1° 14' 1° 08' 1° 06' 1° 02' 1° 01'
11,5
1° 20' 1° 18' 1° 11' 1° 09' 1° 05' 1° 04'
12,0
1° 23' 1° 21' 1° 14' 1° 12' 1° 08' 1° 06'
