Gxxx: Current Transducers (Option, to be ordered separately)
Top view
Height
Width
Depth
Cable
diameter
Front view
Figure B.35: Dimensions
B.8.2 Connection cable LEM CT to MCTS
Connection cable LEM CT to MCTS (Option, to be ordered separately)
Connection cable between LEM current transducer and MCTS power supply. Available in lengths of 2.5 m (8.20 ft), 5 m (16.40 ft) and 10 m
(32.81 ft).
Figure B.36: Connection cable LEM CT to MCTS
GEN3i
752 I3763-3.1 en HBM: public
