HBM GEN3i - Standard Zipcord Fiber Optic Duplex Multi Mode Patch Cable

B.9.4 Standard zipcord fiber optic duplex Multi Mode patch cable
KAB280: Fiber Cable Standard MM LC-LC (Option, to be ordered separately)
Standard zipcord fiber optic duplex Multi Mode patch cable
Tight buffered fiber
Aramid yarn
Outer jacket
Figure B.41: Block diagram and image
Connector type
LC - LC
Glass rating OM3; Multi Mode
Core/Cladding diameter 50/125 μm
Jacket size/diameter Typically 2 mm (0.08") single core
Jacket rating
Low-smoke zero-halogen
Attenuation ≤ 2.7 dB/km @ 850 nm
Available lengths
3, 10, 20 and 50 m (10, 33, 66 and 164 ft). For other lengths contact custom systems
(1)
.
Bend radius 30 mm (1.2")
Weight Typically 14 kg/km (9 lbs/1000 ft)
Operating temperature
-40 °C to +80 °C (-40 °F to 176 °F)
(1) Contact custom systems at: customsystems@hbm.com
Request quote/information for special products for GEN series.
