Capabilities Overview
Model GN441
Maximum sample rate per channel 1 MS/s
Memory per card 512 MB
Analog channels 4
Anti-alias filters Fixed bandwidth analog AA-filter combined with sample rate tracking digital AA-filter
ADC resolution 16 bit
Isolation Channel to channel and channel to chassis
Input type Analog, isolated balanced differential
Passive voltage/current probes
Passive, single-ended isolated voltage probes and Passive, differential matched isolated
voltage probes
Sensors IEPE and current output sensors up to 1 A
TEDS Not supported
Real-time cycle based calculators
Not supported
Real-time formula database calculators (option)
Not supported
EtherCat
®
output Not supported
Digital Event/Timer/Counter Not supported
Standard data streaming (up to 200 MB/s) Supported
Fast data streaming (up to 1 GB/s) Not supported
Slot width 1
