HBM Spider8 - F Specifications

F-1
Specifications
Spider8
F Specifications
Series Spider8 / SR55 Spider8-30 / SR30 Spider8-01SR01
Accuracy class 0.1 0.2
Digital resolution in the case of full scale value Digit "25000
Measurement buffer Meas < 20000
Baud rate
serial
parallel
1)
Nibble mode
8Bit mode
Byte mode (two-way)
EPP mode
USB see data sheet USB
Meas/s
Meas/s
Meas/s
Meas/s
-
600, 1200, 2400, 4800, 9600, 19200, 38400, 57600
> 6500
> 19000
> 24000
> 76000
-
Sampling rate (21 levels) per channel 1/s 1...9600
Digital filter
Aperiodic
Average value
Hz
Hz
0.1
Sampling rate/8 to sampling rate/4
Butterworth (4th order)
Bessel (4th order)
Hz
Hz
0.1...1200
0.1...1200
0.1...200
0.1...200
0.1...1200
0.1...1200
Number of amplifiers 4/1 4/1 1
Transducers that can be connected Strain gauge and ind.
full bridge/half bridge
S/G full bridge / half
bridge/ quarter bridge
-
DC voltage sources
-
DC power sources
Resistors
Thermocouples
Channel 0
2)
and 1
2)
Pulse/frequency
2-phase transmitter
-
Transducer current feed mA 0.25
Transducer excitation voltage V
rms
2.5 -
Carrier-frequency (sine / symmetric) Hz 4800 600 -
Transducer resistance Ω 110...1100 -
Compensating resistors Ω - 120, 350, 700 -
Shunt calibration signal mV/V - 1 -
Transducer cable length up to m 50 200 50
1)
Depends on the power and hardware of the PC.
