Connecting Ý Connecting a printer
Spider8
5 Connecting a printer
Printer
Parallel interface
Printer cable
Printer port (parallel,
LPT1)
13
1. Connect the printer cable to the PRINTER/Slave socket (25-pin)
on the Spider8.
2. Connect the cable to the printer (36-pin printer socket).
Follow the same procedure if using several Spider8 devices (see
also Chap. 4.2).
The printer cable is not included in the list of components supplied.
