Connecting Ý Connecting transducers
Spider8
Connection to Spider8-30
Connection to carrier-frequency module SR30
3.1.4 Single S/G using three-wire connection
8
5
12
Measurement signal
Bridge excitation
voltage
Sensor circuit (open)
Sensor circuit
Bridge excitation
voltage
1
2
3
3’
2’
13
6
bk
wh
bu
15-pin socket
Compensating resistor
(internal):
Pin3: 120
Pin10: 350
Pin9: 700
3
or
10
or
9
120
350
700
R
S/G
Link open
Mode for this connection: quarter bridge.
