Connecting Ý Connecting transducers
Spider8
Example:
SR01: Accuracy class 0.2%
at 100mV: 200µV error
Resolution: 4µV
Thermocouples J, K, T:
Resolution max.: 0.1°C
Error: 2.5°C - 5°C
Thermocouple S:
Resolution max.: 1°C
Error: 25°C - 50°C
Thermocouple with thermal reference element
3
1
2
Ground, potential-
segregated
Thermal
reference element in iced
water at 0
o
C
Thermocouple
Extension wires
Cu wires
Reference measuring point
5-pin terminal
+
-
-+
+
-
U
i
U
i
