CDM 3201 Order No. BA 92-12-3321A Issue 19.09.08 57
Threat to life!
Check whether the welding capacitors are discharged.
Measure the voltage with a commonly used voltmeter (Measurement range direct
current DC/–). The displayed voltage must be below 10 V.
Re-assemble the power unit in reverse sequence.
Make sure that no cables are jammed or sheared during
assembly.
7 Care and Maintenance
7.4 Open the Power Unit
