72 CDM 3201 Order No. BA 92-12-3321A Issue 19.09.08
Spare part list module bottom plate complete CDM 3201 (88-14-079)
Pos. Quantity Order No. Description
9 1 88-10-123 Bottom plate
14 5 80-10-203 Support legs
16 1 80-08-832 Resistor support
18 1 80-50-775 Mains interference filter
23 1 80-57-037 Resistor 30R, 70W
28 1 88-10-106 Rear wall
29 4 80-11-087 Cap
48 2 80-50-766 Fan
53 2 88-10-105 Fan guard
56 2 80-11-408 Stainless steel mesh
62 1 80-10-0128 Solder tag M4
64 2 80-10-0199 Flat connection M4
95 10 80-11-111 Cage nut M4
101 11 80-90-164 Washer 4 mm
102 2 80-90-202 Washer 5 mm
103 13 80-90-121 Spring washer 4 mm
105 3 80-90-128 Spring washer 5 mm
110 8 80-90-153 Nut M4
113 2 80-90-188 Nut M5
114 2 80-90-178 Screw M4 x 12
115 3 80-90-265 Screw M4 x 20
116 2 80-90-199 Screw M5 x 12
117 8 80-90-261 Screw M4 x 10
118 2 80-90-191 Screw M4 x 8
125 2 80-90-280 Screw M4 x 10 black
130 5 80-90-184 Tooth washer A4
131 1 80-90-177 Tooth washer A5
135 8 80-90-252 Blind rivet 4 x 16
143 4 80-11-359 Conductor mark ground cable
146 1 80-11-357 Conductor mark N
147 1 80-11-358 Conductor mark PE
148 1 80-11-356 Conductor mark L1
8 Appendix
8.2 Spare Parts
