IT 1002 Order No BA 93-66-1206 Issue 03.11.08 59
8 Appendix
In the appendix, there is information of interest regarding technical data, spare part lists,
accessories, standards, etc.
8.1 Technical Data
Power Unit IT 1002
for ARC stud welding according to current standards
Welding range #4 to 5/8", dia. 14 ga to 9/16"
(M3 to MR16, dia. 2 to 14 mm)
Welding material Mild steel, stainless steel, aluminum
Welding rate 1/2" (M12) = 25 studs/min
Welding current 1,000 A (max.)
Current adjustment range Stud welding 100 to 1,000 A,
electrode 50 to 400 A (stepless)
Welding time 5 to 1,000 msec (stepless)
Primary power 480/460 V, 3 phases, 50/60 Hz, 35 AT
(alternative input voltages available)
Primary plug 32 A (with 400 V mains)
Connected load 50 kVA (with 400 V mains)
Cooling type F (temperature controlled cooling fan)
Protection class IP 23 (also permits operation outdoors)
Operational and storage conditions According to current standards
Dimension L x W x H 25.98” x 11.02” x 13.39”
(660 x 280 x 340 mm) without handle
Weight 63.93 lbs (29 kg)
