HBS IT 1002 - Adjusting the Welding Time

36 IT 1002 Order No BA 93-66-1206 Issue 03.11.08
Display
2 x 16 digits 5 mm height, with back-lighting
Keys
ENTER, Confirmation of selected function
ARROW, Marks the selected program item
PLUS, Increases the selected value
MINUS, Decreases the selected value
LED’s
They are linked to the process control (see section 5.6.7). The LED’s inform whether
the starting voltage value is in the tolerance range of the reference or not.
Green - value is inside the set tolerance range
Red - value is out of set tolerance range
Basic settings
Using the key Plus , you can enable the process sequence control. You can set the
machine according to your requirements. Call up the main menu with the enter key .
Then the following menu items are available:
- REFERENCE MODE Activate process sequence control
- SET DATE
- SET TIME
- SELECT LANGUAGE
Normally, you select the menu item with the arrow key and open it with the enter
key . To confirm settings and to quit a menu item is also carried out via the enter
key .
5.6.1 Adjusting the Welding Time
 Set the welding time (digital display ) with the arrow keys
(⇑ longer – ⇓ shorter) on the display.
5 Stud Welding Procedure
5.6 Switching on the Power Unit
