62 IT 1002 Order No BA 93-66-1206 Issue 03.11.08
Spare part list front plate complete IT 1002 (88-13-159)
Pos. Quantity Order No. Description
1 1 88-13-160 Operation plate
3 1 88-13-161 Front film operation plate
31 1 80-80-558 P.C. board
32 1 80-70-325 Connection cable
33 1 80-80-559 P.C. board
35 4 80-11-987 Distance sleeve
37 4 80-10-0174 Distance sleeve
39 8 80-11-415 Distance stud
41 2 80-11-111 Cage nut M4
43 1 80-11-121 Flat connection
45 1 80-90-386 Screw M6 x 14
47 1 80-90-197 Tooth lock washer A6
49 2 80-90-198 Washer 6 mm
51 1 80-90-147 Spring washer 6 mm
53 1 80-90-146 Nut M6
55 1 80-11-359 Conductor mark ground cable
8 Appendix
8.2 Spare Parts
