68 IT 1002 Order No BA 93-66-1206 Issue 03.11.08
Spare part list terminal plate complete IT 1002 (88-18-013)
Pos. Quantity Order No. Description
1 1 88-18-014 Terminal plate
31 2 80-50-035 Mounting sleeve
33 1 80-10-0960 Screwed cable connection
35 1 80-11-567 Lock nut M25 x 1,5
41 1 80-50-480 Mains switch
44 1 80-10-0173 Clip-on ferrite
45 2 80-11-111 Cage nut M4
47 4 80-10-576 Flat connection
48 2 80-56-215 Capacitor noise suppression
49 1 80-11-121 Flat connection
61 1 80-11-359 Conductor mark ground cable
71 2 80-90-137 Screw M3 x 8
75 4 80-90-401 Screw M4 x 20
79 4 80-90-153 Nut M4
91 1 80-90-386 Screw M6 x 14
95 1 80-90-197 Tooth lock washer A6
99 2 80-90-198 Washer 6 mm
103 1 80-90-147 Spring washer 6 mm
107 1 80-90-146 Nut M6
