4. The spring (3) and oil strainer
screen (4) will come out when the o i l
strainer screen cap is removed.
(3) Spring (4) Oil strainer screen
(5) O-ring
3. Remove the oil strainer screen cap (2).
(2) Oil strainer screen cap
59
5. Clean the oil strainer screen.
7. Install the oil strainer screen, spring and
oil strainer screen cap. Install the drain
plug
6. Check that the oil strainer screen,
sealing rubber and cap O-ring (5) are in
good condition.
At draining : 0.7 litre
At engine disassembly : 0.8 litre
8. Fill crankcase with the recommended
grade of oil :
9. Install the oil filler oil level dipstick.
10. Start the engine and let it idle for 2-3
minutes. Stop the engine and ensure that
the oil level is at the upper level mark on
the oil level dipstick with the scooter
upright on firm, level ground. Make
sure there are no oil leaks.
2
4
5
3
