0
1 2 3 4 5 6 7 8 9 10 11
AM
PM
km/h
E
F
SERVICE
TRIP
ODO
x 1000 RPM
S
M
Sl. No.
Description
Function
1
2
3
7
5
8
4
The indicators are in the speedometer panel
above the headlamp. The functions are as
below.
Instruments and Indicators
15
9
111315 12
Tachometer
Shows engine revolution per minute. The tachometer
digital segments will swing to maximum scale on the meter
console once the ignition switch is turned “ON”.
1416
Display when the next service is due (page 19).
Speedometer
Indicates riding speed.
Odometer
Shows accumulated distance travelled (page 20).
Tripmeter A & B
Shows the distance travelled during a trip after setting
to zero (page 18).
Service reminder
indicator
Digital clock
Indicates hours & minutes (page 17).
Fuel gauge
Indicates approximate fuel quantity in the form of
digital segments. The fuel gauge segments will display
its maximum scale on the fuel gauge LCD panel once
when the ignition switch it turned "ON" (page 19).
10
6
Scroll display
Displays a scrolling “GET SET GO” message for few seconds
when the ignition switch is turned "ON" (page 18).
1 2 3
84 5 76
